A 4861 • 200W Subwoofer Amplifier
Overview
A compact dedicated subwoofer amplifier providing up to 200W into 4 ohms. Ideally paired with the A 4860 and C 1065 ceiling subwoofer, but is also suitable for any passive subwoofer. Ideal for integration with commercial systems in fashion boutiques, shopping centres, gymnasiums etc. Front panel provides level control, phase adjustment and crossover frequency selection (35Hz – 160Hz). Stereo RCA and speaker level input/outputs provided. Size: 200W x 48H x 220Dmm.
Key Features:
- 200W into 4 ohms
- Stereo RCA input
- Speaker level input and outputs
- Adjustable phase and crossover frequency
- Volume level control
- 240V AC operation
Connection to A 4861 Subwoofer Amplifier:
Specifications
Electrical
Power Output: 200W (RMS @ 4Ω)
Total Harmonic Distortion (THD): <1%(Rated power: 200W @ 4Ω)
Adjustable Low Pass Crossover: 35Hz ~ 160HZ
Frequency Response: 20Hz~20KHz +0/-2dB@ -3dB
Line Level Input Sensitivity: 200mV
Phase Range: 0 ~ 180°
Auto Turn-on Sensitivity: 2mV @ 50 Hz
Trigger In: 12VDC
Thermal Protection: Yes
AC Input: Voltage 115V or 230V
Power Output: 200W (RMS @ 4Ω)
Total Harmonic Distortion (THD): <1%(Rated power: 200W @ 4Ω)
Adjustable Low Pass Crossover: 35Hz ~ 160HZ
Frequency Response: 20Hz~20KHz +0/-2dB@ -3dB
Line Level Input Sensitivity: 200mV
Phase Range: 0 ~ 180°
Auto Turn-on Sensitivity: 2mV @ 50 Hz
Trigger In: 12VDC
Thermal Protection: Yes
AC Input: Voltage 115V or 230V
Mechanical
Dimension: 200mm x160mm x 47.5mm (WxDxH)
Weight: 1.32kg
